Name: PM.4Y
SKU: VC_10541
Availability: InStock

PM.4Y

Capacity

Division

Features

The PM series scales are equipped with an innovative weighing system based on RADWAG's MonoBLOCKTM technology. This allows you to carry out weighings with divisions of 0.01g up to a load of 15kg, and with divisions of 0.1g up to a load of 50kg. Use of the new measurement system patented by Radwag guarantees the stability of the repeatability characteristics over time calculated according to sd<1d. This unique solution is characterized by a very low level of sensitivity to changing environmental conditions. An integrated 4-point system protects the scale from overloads, ensuring safety if excessive loads are placed on the scale plate.

Accessories not found

Data Sheets

PM 4Y.pdf

User Manuals

Please login to download

Models

Description	Capacity	Division	E	Dimensioni Piatto	Omologazione M
PM 10.4Y	10 Kg	0.01 g	0.01 g	200 x 185 mm	X
PM 15.4Y	15 Kg	0.01 g	0.01 g	200 x 185 mm
PM 20.4Y	20 Kg	0.01 g	0.01 g	347 x 259 mm	X
PM 25.4Y	25 Kg	0.1 g	0.1 g	347 x 259 mm	X
PM 35.4Y	35 Kg	0.1 g	0.1 g	400 x 500 mm
PM 50.4Y	50 Kg	0.01 g	0.01 g	400 x 500 mm
PM 60.4Y	60 Kg	0.2 g	0.2 g	200 x 185 mm	X
PM 60.05.4Y	60 Kg	0.5 g	0.5 g	200 x 185 mm
PM 60.1.4Y	60 Kg	1 g	1 g	350 x 260 mm	X
PM 120.4Y	120 Kg	0.2 g	0.2 g	347 x 259 mm	X
PM 10.4Y B	10 Kg	0.01 g	0.01 g	347 x 259 mm	X
PM 15.4Y B	15 Kg	0.01 g	0.01 g	400 x 500 mm
PM 20.4Y B	20 Kg	0.01 g	0.01 g	400 x 500 mm
PM 25.4Y B	25 Kg	0.1 g	0.1 g	200 x 185 mm	X
PM 35.4Y B	35 Kg	0.1 g	0.1 g	200 x 185 mm
PM 50.4Y B	20 Kg	0.1 g	0.1 g	350 x 260 mm	X
PM 60.4Y B	60 Kg	0.1 g	0.1 g	347 x 259 mm	X
PM 60.05.4Y B	60 Kg	0.5 g	0.5 g	347 x 259 mm	X
PM 60.1.4Y B	60 Kg	1 g	1 g	400 x 500 mm
PM 120.4Y B	120 Kg	0.2 g	0.2 g	400 x 500 mm
