Linea
Perché scegliere LINEA?
• Innovazione ed eccellenza operativa: va oltre la pesatura, integrando funzionalità interattive e all'avanguardia.
• Facile e intuitiva: progettata per l'esercente moderno, è perfettamente in linea con le esigenze del mercato attuale.
• Efficienza e profitto: aiuta a ottimizzare il lavoro quotidiano e a migliorare la gestione aziendale.
Tecnologia futuristica per il tuo negozio
• Versatilità di stampa: supporta carta a modulo continuo, rotolo adesivo (2” o 3”) e etichette personalizzate.
• Display full HD da 15”: doppio schermo antisfondamento a colori, touch screen capacitivo per l’operatore e display asincrono per il cliente, ideale per mostrare promozioni.
• Piattaforma gestionale cloud: sistema proprietario che semplifica configurazioni, assistenza e aggiornamenti, offrendo dati preziosi per ottimizzare il business
Capacity
-
Division
-
Features
Technical characteristics:
• 3-inch thermal label printer with label dispenser, 8 dots/mm, 150 mm/sec max
• Paper width: 60mm - 80mm (max. external diameter 100mm),
• Printing on thermal label roll, continuous adhesive label roll, adhesive labels
• Operator and customer-facing screen: 15.6” Full HD resolution (1920x1080)
• Touch screen (operator screen): capacitive, anti-fi ngerprint treatment, suitable for use with
wet
fi ngers and latex gloves
• 1 x USB 3.0, 3 x USB 2.0, 1 x RS232C, 2 x Ethernet TCP/IP (1+1 with passthrough)
• Networking: up to 25 scales
• Wi-Fi and Bluetooth (optional)
• PC, cash register and barcode reader interface
• POS interface (optional)
• Power supply: 100-240 VAC
• External battery feed: 24 VDC +/-10%.
• Dimensions: 360mm (base width), 470mm (depth), 654mm (height)
• Available weights: 12/30kg-2/5g (standard); 30kg-5g; 12kg-2g; 6kg-1g
Functional Features:
• Storable PLUs: unlimited
• Receipt header: 7 lines (max. 200 characters/line)
• Article description (management): max 255 characters
• Management of PLU groups and departments according to user-settable criteria
• Automatic tare, manual tare, tare associated with PLU, programmable tare, cumulative
tare with interactive management in the metrology section
• Programmable tares: 16
• Configurable VAT rates with automatic allocation
• Departments with associated VAT and user-configurable icon
• Management of users and access permissions (passwords) to the various functionalities
• Operators: 16
• Configurable operator keys with name, colour and status indication
• Configurable operator interface and customer-facing screen layouts
• On-screen position of numeric pad and metric section configurable
• Ingredient and recipe management
• Product traceability tracking
• Management of nutritional value tables for products
• Management of EAN-13, EAN-128 and QR Code barcodes
• Display in Full HD resolution (1920x1080) and customer-side display images
• Image import from web, cloud, USB with automatic format optimisation and cropping
function
• Management of date of packing, expiry date and batch
• Print general totals, by operator, by article, by PLU group
• Graphic logo printing
• Printing modes: label, single receipt and consolidated receipt
• Customizing the label layout
• Filterable log of totals and transactions with reprint option
• Quick price change button with adjustable permissions (password)
• Return, discount, reopening of receipt by operator, reversal of receipt by operator
• Customisable keys
• Queue control function
• Generation of a receipt at the till with QR Code
• Advanced cloud features accessible online (management, upgrade, support, backup,
app-store, etc.).
• Scales can operate offline (locally) or online (cloud-connected)
• On-screen receipt preview
• Intuitive, customisable graphical interface, ergonomic menus
• Management functionality (configuration, queries, etc.) via smartphone/tablet
• Interactive metrology section
• Fully interactive operator screen
• Help and online documentation
Description | Code |
---|---|
![]() | ACV-PATCH |
![]() | OSM-SWITCH |
![]() | OPST-24V |
![]() | ACOPRIBILANCIA |
![]() | AND186108102 |
![]() | OCS0PTB |
Data Sheets
User Manuals
Please login to download
Models
Description | Printer | Capacity | Peeler | Division | Finish | Code |
---|---|---|---|---|---|---|
Linea | si | 12/30 Kg | x | 2/5 g | inox | NLNA03-N3 |
Linea | si | 30 Kg | x | 5 g | inox | NLNA03-N3 |
Linea | si | 12 Kg | x | 5 g | inox | NLNA03-N3 |
Linea | si | 6 Kg | x | 1 g | inox | NLNA03-N3 |
