Iscale color professional VISP-C

Functional characteristics
• Connecting 2 platforms with analogue or digital cells
• Independent display of weight and tare value
• Automatic, manual or programmed tare subtraction (also from serial)
• Multiplication of manual or programmed tares
• Totalisation of weighing on two levels (partial and general)
• Per-article totalisation of weight, piece count, and packages
• Management and printing of sequence number and possibility of modification
• Counting function with flexible sampling (including serial input)
• Weight sampling via serial connection to analytical balance
• Manual setting of average unit weight (also from serial)
• Function for calculating volume in litres using specific weight
• Setting the number of packages per weighing
• Direct setting of 4 alphanumeric descriptions, 20 characters each
• Customisation of the 4 associated messages of alphanumeric descriptions
• Article selection from an internal archive via numeric code (0 to 199)
• Printing of receipts with all manageable data on built-in and external printers
• Copy of the last weighing
• Cancellation of last weighing
• Printing of partial and general totals and per article
• Programming article archive (200/1000) with description (16 characters), average unit weight and tare weight
• Article programming and total reading also from serial line
• Programming the tare archive (20)
• Personalisation of receipt header (5 lines)
• Selection of print type (single or cumulative)
• Data transmission on serial line (automatic, continuous, on request)
• Selection of external printer type (continuous roll, tag or label)
• Connection to serial weight repeater

Technical Specifications
Container: stainless steel
• Operating temperature: -10°C to +40°C with maximum humidity 95% non-condensing
• Power supply: 28 VDC (12 VDC if digital)
• 2 m power cable with bipolar plug and grounding (10A, 250 VAC)
• Power consumption: 25W-100mA (standard)
• Cell power supply: 5 VDC
• 24-bit A/D converter
- Display: SMART LCD TFT colour
- Dimensions : 253 x 247 x 133.5 mm
• Connectable platforms: 2
• Interfaces: N°2 RS232 - N°1 USB device - No. 1 Ethernet
• RS485 interfaces: optional
• Approved 10,000 divisions with 3 scale ranges
• Internal resolution 100,000 divisions
• 45-key numeric and alphanumeric keypad
• Programmable auto switch-off device if instrument not in use
• Connection to personal computers, printers, repeaters
- Language selection: 5 options
- Max. cable length: 15m (RS232c)
- Standard protocols: weight
